Pulsar AWO403 Alarmová skříň černá

The Pulsar AWO403 is a professional wall-mounted alarm enclosure designed for security systems, access control, and CCTV applications. Manufactured from 0.8 mm steel sheet with a black RAL 9005 finish, it offers robust protection for your electronic components. The enclosure features a tamper-proof microswitch that detects door opening and wall detachment, ensuring high security. It can accommodate a 12V battery up to 17 Ah and includes cable entries for 4x M16, 2x M20, and 2x M23 glands. Ventilation is provided to maintain optimal operating conditions. The enclosure comes with a key lock (2 keys included) and is CE certified with protection class II.

Advantages

Durable steel construction with tamper protection ensures reliable security for your alarm and control systems. The spacious interior allows for easy installation of components and a large backup battery.

Suitable for

• Alarm systems
• Access control systems
• CCTV systems
• Security installations requiring a wall-mounted enclosure

Key specifications

• Enclosure Type: Wall-mounted
• Material: Steel sheet (0.8 mm)
• Colour: Black (RAL 9005)
• Tamper Protection: Microswitch (door opening, wall detachment)
• Battery Accommodation: Up to 17 Ah/12V
• IP Protection Rating: IP20
• Operating Temperature: -10°C to +40°C
• Lock Type: Key lock (2 keys included)
• Cable Entries: 4x M16, 2x M20, 2x M23
• Ventilation: Yes
• Protection Class: II
• Certifications: CE

Recommendations

For optimal performance, ensure proper cable gland installation and avoid exceeding the maximum battery size. The enclosure is designed for indoor use only.
