DIGITUS OnLine UPS modul 2000Va / 2000W

DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
DIGITUS OnLine UPS modul 2000Va / 2000W
11 927,22 Kč
The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.- High efficiency in online mode, higher ... Zobrazit více
Dostupnost 1 Kód 300091 Značka DIGITUS Model DN-170095 Záruka 2 roky
KategorieOnline UPS

Doprava a vrácení zboží

Předpokládané doručení pátek 6. listopadu
Budeme vás průběžně informovat prostřednictvím našeho podrobného systému sledování zásilek
Možnosti platby
Platební kartaVisaMastercardPayPalApple PayGoogle PayBankovní převod

Popis

The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.

- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.
- High efficiency in online mode, higher efficiency means optimized energy management and lower heat dissipation, resulting in energy savings and improved reliability.
- User-friendly LCD screen provides insight into UPS status for easy installation, configuration and operation.
- Compact rack/tower design optimizes the installation space in the rack and enables flexible installation.
- Minimize device downtime with hot-swappable, user-replaceable battery modules that can be replaced during operation.
- External battery modules allow the runtime to be extended.
- High number of outlets (8 x C13) for optimum power distribution to the consumers.
- Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system.
- Automatic battery self-test and fan speed control increase the service life of the components.
- The REPO function (Remote Emergency Power Off) switches the UPS off in the event of an emergency. If an emergency occurs, the REPO switch turns off the rectifier and the inverter and immediately stops the power supply to the load. The UPS stops charging.

The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers first-class power failure protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructure in both centralized and edge network applications. Scalable runtime options with matching external battery cabinets provide additional flexibility when a longer uninterruptible power supply is required. The user-friendly LCD display and network management capability, including configuration, make this system easy to install and maintain. With market-leading efficiency and unity power factor, the UPS meets your critical application requirements.

Hlavní vlastnosti
  • Online double conversion system (VFI-SS-111)
  • Input: IEC60320 C20 socket, 208/220/230/240 Vac
  • Output: 8 x IEC60320 C13, max. 10A per socket outlet
  • Nominal system power: 2000 VA / 2000 W, power factor 1.0
  • AC-AC (online VFI) efficiency: 93 %, ECO mode efficiency: 98 %.
  • Internal battery pack can be replaced during operation.
  • Battery: Valve-protected, non-spillable lead-acid battery
  • Battery quantity: 4 x 12V x 9.0 Ah
  • Charging: 4 hours to 90% capacity after full discharge
  • Network connection: Optional SNMP/Webcard (part number DN-170100) enables the UPS to be monitored remotely.
  • Local communication ports: USB, RS-232 (serial), SNMP card (optional), relay card (optional)
  • Emergency Power-off (EPO) contact for switching off the UPS in an emergency
  • Maximum operating temperature: 0 - 40 °C
  • Storage temperature: -25 - 55 °C
  • Relative humidity: 20 - 90% non-condensing
  • Operating altitude: < 1500 m
  • Product dimensions WxDxH (mm): 440 (19") x 460 x 86.5 (2U)
  • Product weight: 19.5 kg
  • Shipping dimensions WxDxH (mm): 560 x 590 x 200
  • Shipping weight: 23.7 kg
  • Safety standards: IEC/EN62040-1,IEC/EN60950-1
  • EMC standards: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
  • Optionally available: 19" UPS mounting kit (profile rails), article number DN-170109
  • IP protection class: IP21
  • Heat dissipation: 614 BTU/h
  • Noise level in online mode: approx. 50 dB(A) at a distance of 1 m (may vary slightly depending on load and ambient temperature).

Parametry

Parametry
Barva produktu
Černá
Celní kód Spojeného království
85044085
Doba nabíjení baterie (90 %)
4 h
Formát
Rackmount
Hloubka
460 mm
Hloubka balení
595 mm
Hmotnost
19.5 kg
Hmotnost balíku
22.9 kg
Kabely součástí balení
RS-232, USB cable
Kapacita baterie
9 Ah
Konektor nouzového vypnutí (EPO)
Ano
Maximální proud
10 A
Napájecí zástrčka
C20 coupler
Napětí baterie
12 V
Objem balíku
66705.5 cm³
Odnímatelný napájecí kabel
Ano
Počet podporovaných baterií
4
Počet sériových portů
1
Počet zásuvek AC
8 AC outlet(s)
Port USB
Ano
Porty Ethernet LAN (RJ-45)
2
Příručka
Ano
Provozní nadmořská výška
0 - 1500 m
Provozní teplota (T-T)
0 - 40 °C
Relativní vlhkost při provozu (H-H)
20 - 90%
Relativní vlhkost při skladování (H-H)
20 - 90%
Sada pro montáž do racku
Ano
Šířka
440 mm
Šířka balíku
555 mm
Skladovací teplota (T-T)
-25 - 55 °C
Topologie UPS
Dvojitá konverze (Online)
Typ chlazení
Aktivní
Typ displeje
LCD
Typ konektoru USB
USB Type-B
Typ sériového rozhraní
RS-232
Typ zdroje napájení
AC
Typy zásuvek AC
C13 coupler
Účiník
1
Účinnost
93%
Účinnost (režim ECO)
98%
Velikost (palce)
48.3 cm (19")
Vestavěný ventilátor
Ano
Vstupní provozní napětí (max)
240 V
Vstupní provozní napětí (min)
208 V
Výška
86.5 mm
Výška balení
200 mm
Výstupní výkon
2000 W
Výstupní výkon
1.5 kVA
Země původu
Čína
