DC ovladač Blebox dacBoxD

The Blebox dacBoxD DC Controller is a Wi-Fi-enabled single-channel PWM dimmer designed for controlling 12-24V DC LED strips and other DC loads. It supports voice control via Google Assistant and Amazon Alexa, and can be managed through the BleBox app for iOS and Android. With a maximum output of 4A (96W at 24V), it offers overload, overvoltage, short circuit, and overheating protection. The compact housing is made of self-extinguishing V0 polyurethane and is suitable for flush-mounted boxes (Ø60mm) or direct mounting.

Advantages

Easy Wi-Fi setup, no hub required; works with voice assistants; compact design for discreet installation; comprehensive protection features; open API for integration.

Suitable for

• Controlling 12-24V DC LED strips
• Smart home automation projects
• Voice-controlled lighting

Key specifications

• Control Type: Wi-Fi
• Input Voltage: 12-24V DC
• Output Voltage: 12-24V DC
• Max Output Current: 4A
• Max Output Power: 96W (at 24V)
• Number of Channels: 1
• Dimming Method: PWM
• Wireless Standard: Wi-Fi 2.4GHz (802.11 b/g/n)
• App Control: BleBox App (iOS, Android)
• Voice Assistant Compatibility: Google Assistant, Amazon Alexa
• Operating Temperature: -20°C to 50°C
• Housing Material: Polyurethane composition, self-extinguishing V0
• IP Rating: IP20
• Protection Features: Overload, Overvoltage, Short Circuit, Overheating
• Standby Power Consumption: < 1W
• Mounting Type: Flush-mounted box (Ø60mm) or direct
• Open API Support: Yes

Recommendations

For optimal performance, use with a stable 24V DC power supply and ensure proper ventilation. Compatible with standard 2-wire LED strips.
